P6SMB DEVICES
|
REVERSE STAND-LFF VOLTAGE VRWM(v)
|
BREAKDOWN VOLTAGE Min.@IT VBR Min.(V)
|
BREAKDOWN VOLTAGE Max.@IT VBR Max.(V)
|
TEST CURRENT IT(mA)
|
MAXIMUM CLAMPING VOLTAGE @Ipp VC(V)
|
PEAK PULSE CURRENT Ipp(A)
|
REVERSE LEAKAGE @VRWM IR(uA)
|
|
P6SMB6.8CA/A
P6SMB7.5CA/A
P6SMB8.2CA/A
P6SMB9.1CA/A
|
5.80
6.40
7.02
7.78
|
6.45
7.13
7.79
8.65
|
7.14
7.88
8.61
9.55
|
10
10
10
1
|
10.5
11.3
12.1
13.4
|
58.1
54.0
50.4
45.5
|
1000
500
200
50
|
|
P6SMB10CA/A
P6SMB11CA/A
P6SMB12CA/A
P6SMB13CA/A
|
8.55
9.40
10.20
11.10
|
9.50
10.50
11.40
12.40
|
10.50
11.60
12.60
13.70
|
1
1
1
1
|
14.5
15.6
16.7
18.2
|
42.1
39.1
36.5
33.5
|
10
5
5
5
|
|
P6SMB15CA/A
P6SMB16CA/A
P6SMB18CA/A
P6SMB20CA/A
|
12.80
13.60
15.30.
17.10
|
14.30
15.20
17.10
19.00
|
15.80
16.80
18.90
21.00
|
1
1
1
1
|
21.2
22.5
25.2
27.7
|
28.8
27.1
24.2
22.0
|
5
5
5
5
|
|
P6SMB22CA/A
P6SMB24CA/A
P6SMB27CA/A
P6SMB30CA/A
|
18.80
20.50
23.10
25.60
|
20.90
22.80
25.70
28.50
|
23.10
25.20
28.40
31.50
|
1
1
1
1
|
30.6
33.2
37.5
41.4
|
19.9
18.4
16.3
14.7
|
5
5
5
5
|
|
P6SMB33CA/A
P6SMB36CA/A
P6SMB39CA/A
P6SMB43CA/A
|
28.20
30.80
33.30
36.80
|
31.40
34.20
37.10
40.90
|
34.70
37.80
41.00
45.20
|
1
1
1
1
|
45.7
49.9
53.9
59.3
|
13.3
12.2
11.3
10.3
|
5
5
5
5
|
|
P6SMB47CA/A
P6SMB51CA/A
P6SMB56CA/A
P6SMB62CA/A
|
40.20
43.60
47.80
53.00
|
44.70
48.50
53.20
58.90
|
49.40
53.60
58.80
65.10
|
1
1
1
1
|
64.8
70.1
77.0
85.0
|
9.4
8.7
7.9
7.2
|
5
5
5
5
|
|
P6SMB68CA/A
P6SMB75CA/A
P6SMB82CA/A
P6SMB91CA/A
|
58.10
64.10
70.10
77.80
|
64.60
71.30
77.90
86.50
|
71.40
78.80
86.10
95.50
|
1
1
1
1
|
92.0
103.0
113.0
125.0
|
6.6
5.9
5.4
4.9
|
5
5
5
5
|
|
P6SMB100CA/A
P6SMB110CA/A
P6SMB120CA/A
P6SMB130CA/A
|
85.50
94.00
102.00
111.00
|
95.00
105.00
114.00
124.00
|
105.00
116.00
126.00
137.00
|
1
1
1
1
|
137.0
152.0
165.0
179.0
|
4.5
4.0
3.7
3.4
|
5
5
5
5
|
|
P6SMB150CA/A
P6SMB160CA/A
P6SMB170CA/A
P6SMB180CA/A
|
128.00
136.00
145.00
154.00
|
143.00
152.00
162.00
171.00
|
158.00
168.00
179.00
189.00
|
1
1
1
1
|
207.0
219.0
234.0
246.0
|
2.9
2.8
2.6
2.5
|
5
5
5
5
|
|
P6SMB200CA/A
P6SMB220CA/A
P6SMB250CA/A
P6SMB300CA/A
|
171.00
185.00
214.00
256.00
|
190.00
209.00
237.00
285.00
|
210.00
231.00
263.00
315.00
|
1
1
1
1
|
274.0
328.0
344.0
414.0
|
2.2
1.9
1.8
1.5
|
5
5
5
5
|
|
P6SMB350CA/A
P6SMB400CA/A
P6SMB440CA/A P6SMB480CA/A
|
300.00
342.00
376.00
408.00
|
332.00
380.00
418.00
456.00
|
368.00
420.00
462.00
504.00
|
1
1
1
1
|
482.0
548.0
602.0
658.0
|
1.3
1.1
1.0
0.9
|
5
5
5
5
|
|
P6SMB510CA/A
P6SMB530CA/A
P6SMB540CA/A
P6SMB550CA/A
|
434.00
450.00
459.00
495.00
|
485.00
503.50
513.00
522.50
|
535.00
556.50
567.00
577.50
|
1
1
1
1
|
698.0
725.0
740.0
760.0
|
0.9
0.8
0.8
0.8
|
5
5
5
5
|
Surface-mount
